Weight Optimized Ball Bearing Rear Axle for Porsche 944, 944 S2, 951, 968



RSR9 offers this complete and revised Weight Optimized Ball Bearing Rear Axle for the uncompromising sport driver and for every systematic and consistently built race car.

The OEM rear axle is known for its rubber bearings wearing out causing an unstable rear axle and rumbling noises. Especially the rubber bearings between the rear axle cross tube and the strut often are heavily affected.

Our rebuilt Weight Optimized Ball Bearing Rear Axle painted in silver (RAL 9006) or black (RAL 9005) includes the following upgrades and therefore probably is the best upgrade / replacement option on the market.

  • The rubber bearings between the rear axle cross tube and the strut are replaced by grooved ball bearings (sealed up on both sides)
  • OEM rear rubber bearings (477 501 089) are replaced by heavy duty solid Aluminium Bushings
  • OEM upper rubber mountings (477 501 069A) are replaced by solid Aluminium mounting brackets
  • The OEM two-part struts are replaced by a one-piece upgrade. Torsion bars are completely deleted, height adjustment is carried out via the coilover system only (we recommend the use of the KW Var. 3 or KW Competition). This allows the elimination of changes in toe and resonant intrinsic steering behavior under acceleration and load changes
  • The guiding arm installation points are adapted allowing camber settings from 0° to -4° even when the car is extremely lowered
  • The Rear Axle weighs 9.5kg less than the OEM version

Please note that this upgrade dramatically increases the rigidity of the rear axle, inevitably reducing driving comfort.

Engineered, tested and manufactured in Germany. Race-tested on the Nürburgring Nordschleife.

Product Specification:

  • Completely Rebuilt Rear Axle
  • All rubber bearings are replaced by Aluminium upgrades / grooved ball bearings
  • Torsion bar delete including redesigned one-piece strut
  • Weight saving 9.5kg
  • Camber adjustment of 0° to -4° also when the car is extremely lowered

Core exchange required.

Production lead time (if not in stock) is approx. 10 working days from payment.



€960.00
